Performance Characteristics
FUNCTION: Overload tripping, short-circuit tripping.
SIZE: 2.9 x 3.2 x 1.4inch, Fit for 35mm DIN rail.
CHARACTERISTICS: Rated Current: 50A, Rated Voltage: 230V, For AC 50Hz/60Hz, 2 Pole, Breaking capacity: 6000A
EASY INSTALLATION: Modular sturcture, can be easily installed on the DIN standard guide rail in distribution box, bistable locking clip.
APPLICATIONS: Our miniature circuit breaker is mainly used for overload and short-circuit protection of lighting, power distribution lines and equipment in office buildings, residences and similar buildings. it can also be used for infrequent switching of electrical devices and lighting circuits under normal conditions.
|
Light frame current A |
30MA |
|
Segmentation capacity |
4KA |
|
Release attachment |
overcurrent release |
|
Electrical lifespan improvement |
6000 times |
|
Release characteristics |
C |
|
Protection type |
short circuit/surge protection |
|
Release method |
overcurrent release device |
|
Release screw current |
30ma |
|
Wire replacement method |
front panel wiring |
|
Poles Number |
1P +N,2P, 3P,3P+N 4P |
|
Rated frequency |
50/60HZ |
|
Segmentation capability |
4.5/6/10ka |
An international transformer supplier since 2006
An international transformer supplier since 2006 .we provide vigorous performance and modern technology,which are the principles of our company's corporate structure.
our product range
Miniature circuit breakers are devices that protect circuits and are widely used in residential, commercial, industrial and other fields. It can quickly cut off the power supply in case of overload or short circuit in the circuit, thereby protecting the safety of electrical equipment and circuits.
The scope of application of miniature circuit breakers includes but is not limited to single-phase and three-phase circuits, as well as short circuit protection and overload protection. In addition, it can also be used to protect the circuit facilities of buildings from overcurrent and similar purposes.
